1 Channel Single Mode FC Digitally Encoded Video with Bidirectional Data FTV10D1S1FC

Also Known As:

1 Channel Transmitter, Single Mode Transmitter, FC Connector, Digitally Encoded Video

About:

The FTV10D1S1FC fiber transmitter allow transmission of one unidirectional composite video channel and one bidirectional data channel over one optical fiber. In addition, the “up-the-coax” technology allows Coaxitron pan/tilt/zoom (PTZ) control data to be transmitted the full distance of the fiber (up to 48 km for single-mode fiber). When using single-mode fiber, the FTV10D1S1FC transmitter offer an optical power budget of 23 dB. The FTV10D1S1FC plug-and-play design ensures ease of installation by requiring no electrical or optical adjustments. Modular in design, FTV10D1S1FC unit can be rack-mounted using the EURACK/USRACK chassis, or stand-alone modules can be placed on a desktop or mounted to a wall (wall mount kit not required).

Features:

• Laser Diode for Transmission of Optical Signals
• Stand-Alone and Rack-Mountable Modular Design
• Compatible with NTSC, PAL, and SECAM Video Standards
• Single-Mode Fiber Support for Distances up to 69 km (43 mi)
• Exceeds All Requirements for RS-250C Short-Haul Transmission
• LED Status Indicators for Monitoring All Critical Operating Parameters
• 10-Bit Digitally Encoded Video for High-Quality Video Transmission over a Single Fiber
• Supports Pelco Coaxitron “Up-the-Coax” Control Signals for a Distance up to 48 km (30 mi)
• Designed to Meet NEMA TS-1/TS-2 and Caltrans Traffic Signal Control Equipment Environmental Standards
• Bidirectional Data Channel that Supports RS-232, RS-422, RS-485 (2-wire/4-wire), Manchester, Bi-Phase, and Coaxitron Communication

Specifications:

• Product Type: Transmitter
• Channels: 1 Channel
• Connection Type:  FC
• Part Number : FTV10D1S1FC
